C-7/EC72
| Size | TRA Code | Ply Rating | Standard Rim | Tread Depth (mm) | Overall Diameter (mm) | Section Width (mm) | Max. Load Capacity (kg) | Cold Inflation Pressure (kPa) | TT/TL |
|---|---|---|---|---|---|---|---|---|---|
| 14.9-24 | EC72 | 8 | W13 | 21.0 | 1241 | 378 | 1760 | 180 | TT/TL |
| 18.4-26 | EC72 | 12 | DW16 | 23.0 | 1400 | 440 | 2985 | 230 | TT/TL |
| 23.1-26 | C-7 | 8 | DW20 | 17.0 | 1500 | 595 | 4000 | 140 | TT/TL |
| C-7 | 12 | DW20 | 17.0 | 1500 | 595 | 5150(10km/h) | 200 | TT/TL |
*Reserves the rights of final interpretation and modification;
 |
 |
 |
 |
 |
