R-4
| Size | TRA Code | Ply Rating | Standard Rim | Tread Depth (mm) | Overall Diameter (mm) | Section Width (mm) | Max. Load Capacity (kg) | Cold Inflation Pressure (kPa) | TT/TL |
|---|---|---|---|---|---|---|---|---|---|
| 17.5L-24 | R-4 | 12 | W15L | 25.5 | 1241 | 434 | 2995 | 250 | TL |
| 19.5L-24 | R-4 | 12 | DW16A | 27.0 | 1314 | 485 | 3450 | 230 | TL |
| R-4 | 14 | DW16A | 27.0 | 1314 | 485 | 3750 | 260 | TL | |
| 21L-24 | R-4 | 12 | DW18A | 27.5 | 1378 | 533 | 3875 | 220 | TL |
*Reserves the rights of final interpretation and modification;
 |
 |
 |
 |
 |
